Proper use of Teflon conveyor belt

Reasonable and standardized use of Teflon conveyor belt can extend the service life of the conveyor belt.

Non stick PTFE open mesh conveyor belt is also called Teflon mesh belt、high temperature PTFE mesh, Teflon conveyor belt is divided into Teflon mesh conveyor belt and Teflon coated fiberglass belt, Both of them are using glass fiber cloth coated with Teflon resin to make Teflon (PTFE) conveyor belt base cloth; Among them, Teflon mesh conveyor belts are defined by mesh size, mainly including 1×1MM, 2×2.5MM, 4×4MM, 10×10MM, etc. And according to the difference of the warp and weft, it is divided into single weft and double weft Teflon mesh conveyor belts; Teflon coated fiberglass belt is divided into specifications by thickness, and the thinnest can reach 0.08MM.

Our factory supports the customization of various specifications of Teflon conveyor belts, and provides free samples of various specifications of Teflon conveyor belts.

Teflon mesh conveyor with mesh holes, good breath-ability, So it is widely used in textile printing and dyeing, printing drying guide belt, screen printing, ultraviolet drying, UV series, light curing machine, offset printing machine, loose dryer, non-woven dryer, high frequency dryer, food baking machine guide belt, temperature control drying room, rapid drying of flux-type ink and drying of general moisture content items.

food baking machine
Application of Teflon conveyor belt in food baking machine

Teflon conveyor belt has very good weather resistance, anti-aging properties, The surface of the Teflon conveyor belt is not sticky, it is not easy to adsorb any substance, and various oil stains are easy to clean. At the same time, Teflon conveyor belt has very good chemical resistance, and it can be used normally in both strong acid and alkali environments. Usually Teflon conveyor belt can work at low temperature -70℃ to high temperature 260℃, some customized Teflon conveyor belt can work normally at 350℃ high temperature, will not reduce the performance of the product due to temperature changes.

All conveyor belts are consumables, and Teflon conveyor belts are no exception. In order to maximize the use life of Teflon conveyor belts, we recommend that you pay attention to the following details when using Teflon conveyor belts.

During the use of the Teflon conveyor belt, do not cause excessive local stress. The items should be evenly distributed on the Teflon conveyor belt to avoid tearing the conveyor belt due to excessive local stress.

Regularly clean the foreign objects on the Teflon conveyor belt to prevent the foreign objects from causing local rupture with the operation of the Teflon conveyor belt.

Regularly check the position of the working roller of the Teflon conveyor belt, pay attention to keep it level, and avoid uneven tension.

Teflon conveyor belt joints need to be neatly connected. There are many types of Teflon conveyor joints, no matter which way you should pay attention to keep it tidy, otherwise it is easy to break.

If you have any questions during the use of Teflon conveyor belt, please contact us at info@jiujiangptfe.com. Our engineers will reply to you within 24 hours.
